TOYOTA HILUX DIESEL

Emissions - ICE

• CO
  0.034
• HC
  Not Available
• HC+NOx
  0.03
• Noise Level dB(A)
  69
• NOx
  0.023
• Particles
  0.0015
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb
  254
• WLTP - CO2 (g/km) - Comb - TEH
  268
• WLTP - CO2 (g/km) - Comb - TEL
  250
• WLTP - CO2 (g/km) - Extra High
  260
• WLTP - CO2 (g/km) - Extra High - TEH
  275
• WLTP - CO2 (g/km) - Extra High - TEL
  253
• WLTP - CO2 (g/km) - High
  216
• WLTP - CO2 (g/km) - High - TEH
  230
• WLTP - CO2 (g/km) - High - TEL
  212
• WLTP - CO2 (g/km) - Low
  332
• WLTP - CO2 (g/km) - Low - TEH
  348
• WLTP - CO2 (g/km) - Low - TEL
  330
• WLTP - CO2 (g/km) - Medium
  252
• WLTP - CO2 (g/km) - Medium - TEH
  262
• WLTP - CO2 (g/km) - Medium - TEL
  250

Engine and Drive Train

• Automatic Transmission
  Yes
• Bore
  92
• Catalytic Convertor
  Yes
• CC
  2755
• Compression Ratio
  15.6:1
• Cooling System
  WATER
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Engine Codes
  1GD-FTV
• Engine Layout
  NORTH SOUTH
• Engine Make
  Not Available
• Fuel Delivery
  COMMON RAIL
• Fuel Type
  DIESEL
• Gears
  6 SPEED
• Manual Transmission
  No
• Number of Valves
  16
• Stroke
  103.6
• Valve gear
  DOHC

Fuel Consumption - ICE

• EC
  No
• WLTP - FC (l/100km) - Comb
  9.7
• WLTP - FC (l/100km) - Comb - TEH
  10.2
• WLTP - FC (l/100km) - Comb - TEL
  9.5
• WLTP - FC (l/100km) - Extra High
  9.9
• WLTP - FC (l/100km) - Extra High - TEH
  10.5
• WLTP - FC (l/100km) - Extra High - TEL
  9.6
• WLTP - FC (l/100km) - High
  8.2
• WLTP - FC (l/100km) - High - TEH
  8.8
• WLTP - FC (l/100km) - High - TEL
  8.1
• WLTP - FC (l/100km) - Low
  12.7
• WLTP - FC (l/100km) - Low - TEH
  13.2
• WLTP - FC (l/100km) - Low - TEL
  12.6
• WLTP - FC (l/100km) - Medium
  9.6
• WLTP - FC (l/100km) - Medium - TEH
  10
• WLTP - FC (l/100km) - Medium - TEL
  9.5
• WLTP - MPG - Comb
  29.1
• WLTP - MPG - Comb - TEH
  27.7
• WLTP - MPG - Comb - TEL
  29.7
• WLTP - MPG - Extra High
  28.5
• WLTP - MPG - Extra High - TEH
  26.9
• WLTP - MPG - Extra High - TEL
  29.4
• WLTP - MPG - High
  34.4
• WLTP - MPG - High - TEH
  32.1
• WLTP - MPG - High - TEL
  34.9
• WLTP - MPG - Low
  22.2
• WLTP - MPG - Low - TEH
  21.4
• WLTP - MPG - Low - TEL
  22.4
• WLTP - MPG - Medium
  29.4
• WLTP - MPG - Medium - TEH
  28.2
• WLTP - MPG - Medium - TEL
  29.7

General

• Alternative Fuel Qualifying
  No
• Alternator Amps
  Not Available
• Did at least one aspect of this vehicles safety give cause for concern?
  No
• Badge Engine CC
  2.8
• Badge Power
  204
• Based On ID
  Not Available
• Chassis Engine Number
  Not Available
• Clutch
  SINGLE DRY PLATE
• Coin Description
  Not Available
• Coin Gross Vehicle Weight Code
  Not Available
• Coin Power Output Code
  Not Available
• Coin Series
  Not Available
• Coin Wheelbase Description Code
  Not Available
• Coin Wheelbase Name Code
  Not Available
• Exhaust System
  CATALYTIC CONVERTER
• Front Brakes
  VENTILATED DISCS
• Front Suspension
  DOUBLE WISHBONE
• Generation Mark
  9
• Ghost model for valuation purposes
  No
• Hand Brake
  REAR
• Manufacturers Corrosion Perforation Guarantee - Years
  6
• Manufacturers Paintwork Guarantee - Years
  3
• NCAP Adult Occupant Protection %
  Not Available
• NCAP Child Occupant Protection %
  Not Available
• NCAP Overall Rating - Effective February 09
  Not Available
• NCAP Overall Rating - LCV
  Not Available
• NCAP Pedestrian Protection %
  Not Available
• NCAP Safety Assist %
  Not Available
• Rear Brakes
  VENTILATED DISCS
• Rear Suspension
  LEAF SPRINGS
• Relative Height
  H1
• Relative Length
  L1
• Running Cost League Headings
  MEDIUM
• Service Interval Frequency - Months
  12
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  5
• Steering
  PAS RACK AND PINION
• This vehicle is classed as a car for VED purposes
  No
• Vehicle Homologation Class
  N1
• Vin/Frame No.
  Not Available

Performance

• 0 to 62 mph (secs)
  12.6
• BHP
  204
• Engine Power KW
  150
• Engine Power RPM
  2800
• Engine Torque LBS.FT
  369
• Engine Torque MKG
  51
• Engine Torque NM
  500
• Engine Torque RPM
  1600
• Top Speed
  109

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Automatic Clutch
  Yes
• Plated 3rd Axle
  Not Available
• Plated 4th Axle
  Not Available
• Space Saver?
  No
• Tyre Make
  Not Available
• Tyre Size Front
  265/65 R17
• Tyre Size Rear
  265/65 R17
• Tyre Size Spare
  FULL SIZE
• Wheel Style
  6 DOUBLE SPOKE
• Wheel Type
  17" ALLOY

Vehicle Dimensions

• Front Overhang
  990
• Height
  1865
• Height (including roof rails)
  Not Available
• Length
  5320
• Load Deck Height
  480
• Load Height
  1165
• Load Length
  1676
• Load Width
  1438
• Lower Rear Door Width
  Not Available
• Rear Door Height
  Not Available
• Rear Overhang
  1245
• Side Load Door Height
  Not Available
• Side Load Door Width
  Not Available
• Turning Circle - Kerb to Kerb
  6.3
• Turning Circle - Wall to Wall
  6.8
• Upper Rear Door Width
  Not Available
• Wheelbase
  3085
• Width (excluding mirrors)
  1885
• Width (including mirrors)
  Not Available

Weight and Capacities

• Boot Capacity Saloons
  Not Available
• Fuel Tank Capacity (Litres)
  80
• Gross Train Weight
  6300
• Gross Vehicle Weight
  3250
• Load Space Volume
  Not Available
• Luggage Capacity (Seats Down)
  Not Available
• Luggage Capacity (Seats Up)
  Not Available
• Luggage Capacity - 2nd Row Seats Removed
  Not Available
• Luggage Capacity - 2nd Row Seats Up
  Not Available
• Luggage Capacity - 3rd Row Seats Down
  Not Available
• Luggage Capacity - 3rd Row Seats Removed
  Not Available
• Luggage Capacity - 3rd Row Seats Up
  Not Available
• Max. Roof Load
  140
• Max. Towing Weight - Braked
  3500
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  2185
• No. of Seats
  5
• Payload
  1065
• Plated 2nd Axle
  1555
• Plated Front Axle
  1540
