PEUGEOT e-PARTNER STANDARD

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  70
• Battery Capacity in kWh
  52
• Battery Charging Scenario 1 - Charge Time (Mins)
  1870
• Battery Charging Scenario 1 - Percentage Change
  0-100
• Battery Charging Scenario 1 - Power Supply - kW
  1.8
• Battery Charging Scenario 2 - Charge Time (Mins)
  450
• Battery Charging Scenario 2 - Percentage Change
  0-100
• Battery Charging Scenario 2 - Power Supply - kW
  7.4
• Battery Charging Scenario 3 - Charge Time (Mins)
  304
• Battery Charging Scenario 3 - Percentage Change
  0-100
• Battery Charging Scenario 3 - Power Supply - kW
  11
• Battery Charging Scenario 4 - Charge Time (Mins)
  30
• Battery Charging Scenario 4 - Percentage Change
  0-80
• Battery Charging Scenario 4 - Power Supply - kW
  100
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Left Side Rear
• Coupler/Connector Type
  CCS Type 2
• Maximum Charging Rate - kW
  100
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  8
• Usable Battery Capacity
  50.57
• WLTP - EC (kWh/100km) - Comb - TEH
  21.7
• WLTP - EC (kWh/100km) - Comb - TEL
  17.4
• WLTP - EC (miles/kWh) - Comb - TEH
  2.9
• WLTP - EC (miles/kWh) - Comb - TEL
  3.6
• WLTP - Pure Electric Range (km) - City
  490
• WLTP - Pure Electric Range (km) - City - TEH
  391
• WLTP - Pure Electric Range (km) - City - TEL
  490
• WLTP - Pure Electric Range (km) - Comb
  343
• WLTP - Pure Electric Range (km) - Comb - TEH
  289
• WLTP - Pure Electric Range (km) - Comb - TEL
  354
• WLTP - Pure Electric Range (miles) - City
  304
• WLTP - Pure Electric Range (miles) - City - TEH
  243
• WLTP - Pure Electric Range (miles) - City - TEL
  304
• WLTP - Pure Electric Range (miles) - Comb
  213
• WLTP - Pure Electric Range (miles) - Comb - TEH
  180
• WLTP - Pure Electric Range (miles) - Comb - TEL
  220

Emissions - ICE

• CO
  Not Available
• CO2
  Not Available
• HC
  Not Available
• HC+NOx
  Not Available
• Noise Level dB(A)
  Not Available
• NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  Not Available

Engine and Drive Train

• Automatic Transmission
  Yes
• Bore
  Not Available
• Catalytic Convertor
  Not Available
• CC
  1
• Compression Ratio
  Not Available
• Cooling System
  Not Available
• Cylinder Layout
  Not Available
• Cylinders
  Not Available
• Engine Codes
  Not Available
• Engine Layout
  Not Available
• Engine Make
  Not Available
• Fuel Delivery
  Not Available
• Fuel Type
  Not Available
• Gears
  1 SPEED
• Manual Transmission
  No
• Number of Valves
  Not Available
• Stroke
  Not Available
• Valve gear
  Not Available

Fuel Consumption - ICE

• EC
  Not Available
• EC Combined
  Not Available
• EC Extra Urban
  Not Available
• EC Urban
  Not Available

General

• Alternative Fuel Qualifying
  Yes
• Alternator Amps
  Not Available
• Did at least one aspect of this vehicles safety give cause for concern?
  No
• Badge Engine CC
• Badge Power
  136
• Based On ID
  Not Available
• Battery AH
  Not Available
• Chassis Engine Number
  Not Available
• Clutch
  Not Available
• Coin Description
  Not Available
• Coin Gross Vehicle Weight Code
  Not Available
• Coin Power Output Code
  Not Available
• Coin Series
  Not Available
• Coin Wheelbase Description Code
  Not Available
• Coin Wheelbase Name Code
  Not Available
• Exhaust System
  Not Available
• Front Brakes
  VENTILATED DISCS
• Front Suspension
  MACPHERSON STRUTS
• Generation Mark
  3
• Hand Brake
  REAR WHEELS
• Rear Brakes
  DISCS
• Rear Suspension
  COIL SPRINGS
• Relative Height
  H1
• Relative Length
  L1
• Running Cost League Headings
  SMALL
• Service Interval Frequency - Months
  24
• Service Interval Mileage
  25000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  3
• Steering
  PAS RACK AND PINION
• This vehicle is classed as a car for VED purposes
  No
• Timing Belt Interval Frequency - Months
  Not Available
• Timing Belt Interval Mileage
  Not Available
• Vehicle Homologation Class
  N1
• Vin/Frame No.
  Not Available

Performance

• 0 to 62 mph (secs)
  11.7
• BHP
  136
• Engine Power KW
  100
• Engine Power RPM
  5500
• Engine Torque LBS.FT
  199
• Engine Torque MKG
  27.5
• Engine Torque NM
  270
• Engine Torque RPM
  3674
• Top Speed
  82

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  Not Available

Tyres

• Alloys?
  No
• Automatic Clutch
  Yes
• Plated 3rd Axle
  Not Available
• Plated 4th Axle
  Not Available
• Space Saver?
  No
• Tyre Make
  Not Available
• Tyre Size Front
  215/65 R16
• Tyre Size Rear
  215/65 R16
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Not Available
• Wheel Type
  16" STEEL

Vehicle Dimensions

• Front Overhang
  892
• Height
  1860
• Height (including roof rails)
  Not Available
• Length
  4403
• Load Deck Height
  588
• Load Height
  1200
• Load Length
  1817
• Load Space Width Between Wheel Arches
  1229
• Load Width
  1630
• Lower Rear Door Width
  1241
• Rear Door Height
  1196
• Rear Overhang
  726
• Side Load Door Height
  1072
• Side Load Door Width
  675
• Turning Circle - Kerb to Kerb
  10.8
• Upper Rear Door Width
  1087
• Wheelbase
  2785
• Width (excluding mirrors)
  1848
• Width (including mirrors)
  2107

Weight and Capacities

• Boot Capacity Saloons
  Not Available
• Fuel Tank Capacity (Litres)
  Not Available
• Gross Train Weight
  3200
• Gross Vehicle Weight
  2450
• Load Space Volume
  3.3
• Luggage Capacity (Seats Down)
  Not Available
• Luggage Capacity (Seats Up)
  Not Available
• Luggage Capacity - 2nd Row Seats Removed
  Not Available
• Luggage Capacity - 2nd Row Seats Up
  Not Available
• Luggage Capacity - 3rd Row Seats Down
  Not Available
• Luggage Capacity - 3rd Row Seats Removed
  Not Available
• Luggage Capacity - 3rd Row Seats Up
  Not Available
• Max. Towing Weight - Braked
  750
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  1691
• No. of Seats
  3
• Payload
  759
• Plated 2nd Axle
  1400
• Plated Front Axle
  1200
